Usiland Optronics, a professional laser cleaning machine manufacturer & supplier!
Latest Smart Grid Cleaning Device Smart Grid Cleaning Device Company
Product details of the smart grid cleaning device
Product Introduction
Modern production technology improves Usiland Optronics smart grid cleaning device production. The product is of a very high standard quality, well-recognized among customers. The product is the most potential product for growth in the industry.
Product Advantage
Basic Parameters
This series of laser power grid foreign object removal devices is specifically designed for the rapid removal of exposed power grid foreign objects, providing an ideal and efficient remote laser foreign object removal device for maintaining the safety of power grids and high-speed railway lines.
|
Project name |
UAV-Cyclone 1000 |
|
Size[mm³] |
630*490*312 |
|
Weight[kg] |
39 |
|
Laser power[W] |
1000+50 |
|
Power range[%] |
20-100 |
|
Wavelength[mm] |
1080 |
|
Working distance [m] |
400 |
|
Humidity [%] |
10– 90 |
|
Working temperature [℃] |
-20~40 |
|
Fiber length[cm] |
300 |
|
Battery specification[V AH] |
48V 83AH |
|
Working hours[H] |
1.2 |
|
Battery weight[kg] |
20 |
|
Power consumption [W] |
3300 |
|
Cooling system |
Air cooling |
*Note: For reference only, the specific material and width of the material to be removed are related.
Working Principle
High-energy laser is utilized to instantly dissolve foreign objects entangled in high-voltage lines without damaging transmission lines.
When it is found that there is a foreign object hanging on the grounding wire that affects safe operation, the operator aims at the target through a sight on the ground, controls the laser device to emit laser.
Through several seconds of burning and melting, the plastic-fiber foreign object is melted off, and the laser is turned off, thus completing the entire processes of handling foreign object with electricity.
The target objects of the smart grid cleaning device mainly include balloons, kites, and plastic bags.
The 1000W model, with high power, is specifically designed for clearing tree branches (above 10cm).
Product Details
Steps for usage
Safety Design
Company Feature
• Usiland Optronics has a high-quality management team, a professional management team, and a considerate service team. This provides a good guarantee for production, sales, and service.
• With good location advantages, the open and easy traffic serves as the foundation for Usiland Optronics's development.
• Our company was founded in We actively extend the industrial chain and strive to strengthen the organic connection between R&D, production, processing, sales and service. And through years of exploration, the industrialization management is beginning to take shape.
• Our company is able to provide customers with high-quality products and professional services promptly, because we have established a relatively complete service system.
Want to get a durable high-tech laser cleaning machines,laser bird deterrent? Please contact Usiland Optronics.
