Fully Automatic Tire Mold Cleaning System | Uisland Optronics
The S-TMCS-500 features 6 high-frequency picosecond laser heads with adjustable laser frequencies, suitable for various mold materials and precision requirements to ensure uniform and accurate cleaning of tire molds. Equipped with an automatic cleaning system, it enables fully unmanned operation to save time and labor, and is also fitted with an alarm system to avoid accidental mold damage and eliminate operational risks for personnel.
This system delivers excellent cleaning results, conserves resources and enhances efficiency. Its water‑air flow system generates strong air pressure to thoroughly clean tire molds with no residues. Rigorously tested for quality, the equipment ensures high performance, durability and reliability, and comes with a user-friendly interface and manual for fast, easy operation.
Related Parameter
| Project name |
Parameter data |
| Working mode | Automatic |
| Single pulse energy [mJ] |
50 |
| Cooling system | Water cooling |
| Laser power [W] |
500 |
| Wavelength [nm] | 1064 |
| Humidity [%] | 10-95(non-condensible) |
| Cleaning efficiency [Min] |
25-45 |
| Power supply | 220V AC |
| Switch machine time [s] |
Time ＜30 |
| Cleaning size [inch] | 11-75 |
| Laser level |
IV |
*Minimum / Maximum ambient temperature [℃]: 5-40
*Intelligent operation
One-click operation, With ERP/MES function, production history and video inquiry.
*Laser cleaning head
＜1.5kg, with Galvanometer feedback function, Effective protection of cleaning tools.
*Cleaning method
Fully automatic cleaning of side panel and pattern block(you don't need to disassemble the mold sleeve insulation sleeve or disassemble the mold sleeve in blocks to place automatic cleaning, two kinds of automatic process cleaning and two half molds).
